Technical documents and installation manuals

Installation instructions, care sheets and material data for the products we manufacture. The cubicle fitting guide is available to download; other sheets are issued against the order or product.

Browse the ranges Talk to the factory

This is the document library for products manufactured at our Bolton factory. Installation instructions, care and maintenance sheets, material data and compliance paperwork sit here. The cubicle installation guide can be downloaded below. Other documents are issued against a product and a build, because a care sheet or fire certificate written for one specification is not the sheet for another.

If you need a range-specific or order-matched revision, ask the Bolton office with the order number. You get the document that matches what was actually made for you.

Downloads by product family

The cubicle fitting guide is on this page. IPS, hardware, worktops, cut panels and furniture sheets are issued against the product or the order, because a care sheet written for one specification is not the sheet for another. The archived manuals collection template held vanity copy, not extra PDFs; unique family coverage is folded in here.

Cubicles

Cubicles

Cubicle installation instructions

Fixing sequence, bracket positions and adjustment for the Smart, Ascent, Tippy Toes, Blossom and Alpine ranges. Download the current fitting guide as a PDF.

Download PDF

IPS systems

  • IPS panel installation

    Setting out, fixing to studwork or masonry, access panel handling and tolerances for duct runs. The full written guide is on this site, with a printable sheet available on request.

    Read the IPS installation guide

Cubicle hardware

  • Hardware fitting sheets

    Fitting and adjustment notes for hinges, indicator bolts, coat hooks, brackets and feet, including retrofit into existing cubicles. Send a photograph of the ironmongery if you are unsure which set you have.

    Identify your hardware

Worktops, cut panels and furniture

  • Care and cleaning

    How to clean laminate faces, compact grade laminate and postformed edges without damaging them, and which cleaners to keep away from the board. Relevant to FM handover packs. Issued for MFC, MR MDF, FR MDF, compact laminate and postformed worktops.

    Request document

  • Material and compliance data

    Board technical data, laminate details and the certification that applies to your specific build-up, plus Made in Britain, Constructionline Gold and SSIP paperwork for supplier approval. Cut-panel and furniture orders use the same pack, matched to the board that was actually cut.

    Request document

Specification

Document index: what is available, what it covers and how it is issued
Document Applies to Format
Cubicle installation instructions Smart, Ascent, Tippy Toes, Blossom and Alpine ranges PDF, download from this page
IPS panel installation guide IPS duct panels, access panels and IPS units On-page guide, plus a printable PDF on request
Hardware fitting and adjustment sheet Hinges, indicator bolts, brackets, feet and coat hooks PDF on request, retrofit notes included
Care and cleaning guidance MFC, MR MDF, FR MDF, compact laminate and postformed surfaces PDF, suitable for O and M and handover packs
Board and laminate technical data The specific board and decor supplied on your order PDF, issued against your order number
Fire performance certification The exact laminate and core specified on your job Issued per build-up. No single site-wide rating exists
Company and accreditation pack Made in Britain, Constructionline Gold, SSIP, Social Value PDF pack for supplier approval and PQQs
Insurance schedule and delivery method statement Supply-only orders and deliveries to site PDF on request at enquiry stage

Why buy direct from the manufacturer

  • Current revision, not stale

    The cubicle installation guide is published on this page. Care sheets, material data and fire certification are issued against your order number, so the revision matches the build you received.

  • Certificates match your build

    Fire performance depends on the laminate and core specified, so we issue the certification for your build-up rather than a blanket rating that would not survive scrutiny.

  • Ask the factory directly

    The Bolton office holds the drawings and the production record for your job. If a document you need is not listed here, ask and we will produce it.

Common questions

Why are most documents not direct downloads?

Because a file left on a page can go out of date and then get quoted back at us on site. The cubicle installation guide is published here as a PDF. Care sheets, material data and fire certification are still issued on request against your order number so the revision matches what was manufactured for you. Ask the Bolton office and it comes back by email, usually within the working day.

Which cubicle installation sheet do I need?

Start with the PDF on this page. It covers the fitting sequence used across Smart, Ascent, Tippy Toes, Blossom and Alpine. If the hardware or fixing set on your order differs, quote the range name and the order number and Bolton will issue the matching notes.

Do you publish a fire rating for your panels?

No, and be careful of any supplier who publishes one figure for a whole product range. Fire performance depends on the laminate and the core specified on your particular job. Tell us the requirement at enquiry stage and we will build to it and issue the certification that applies to that build-up.

Can I get documents for an installation that predates my time on site?

Often, yes. If you can find an order number, a delivery note or a drawing reference we can look up what was made and issue the matching sheets. Failing that, send photographs of the cubicles and the ironmongery and we will identify the range and hardware set from Bolton.

What do you need for a supplier approval or PQQ?

Ask for the company and accreditation pack. It covers Made in Britain, Constructionline Gold, SSIP and Social Value membership, with company number 03537823 and VAT number 329278768. Insurance schedules and material data go in the same pack. Request it at enquiry stage so approval is not holding up an order later.

Do installation documents cover fitting by my own contractor?

Yes. We supply, and in most cases your own fitters install. The sheets are written for a competent joiner or shopfitter and cover sequencing, fixings, adjustment and tolerances. They do not cover the substrate itself, so wall build-up, studwork centres and floor level remain the responsibility of the installer on site.
